01
24-bit signal acquisition
Upgraded from the previous 12-bit architecture to a 24-bit ADC. The manufacturer describes a medical-grade amplifier for finer EMG signal acquisition.
OYMotion · EMG ARMBAND
gForce Ultra
Turn muscle signals into data and interaction. A new armband combining 8-channel dry EMG and a 6-axis IMU for signal analysis and gesture-based application development.
24-bit ADC8ch EMG6-axis IMURaw + Gesture
Updated acquisition and gesture recognition
02
Raw signals and recognition together
Outputs raw EMG data and gesture recognition results simultaneously, enabling signal analysis alongside recognition logging and control algorithm development.
03
General-purpose gesture model
Supports a general-purpose gesture recognition model. The manufacturer plans continued model improvements through future software updates.
A closer look inside the band
Explore the inner electrodes and fastening structure of the open band.
Specifications
Based on page 2 of the product brochure. ADC and EMG sampling rates are listed separately.
- EMG electrodes
- 8-channel dry electrodes
- ADC resolution
- 24-bit
- ADC sampling rate
- 1,000 Hz
- EMG sampling rate
- 500 Hz
- IMU
- 6-axis · 50 Hz
- Communication
- BLE 4.2
- Main unit (L × W × H)
- 53 × 28 × 17 mm
- Wristband length
- XS 190 / S 202 / M 216 / L 230 mm (±2 mm)
- Battery
- Lithium polymer · 200 mAh
- Operating time
- 5 hours (manufacturer specification)
- Rated current
- 30 mA
- Indicators
- Green status LED · orange charging LED
- Button
- Power on / off
Specification source: OYMotion gForce Ultra brochure, pages 1–2. View source PDF
Wireless connectivity roadmap
The current brochure specifies BLE 4.2. Bluetooth 5.0 is planned for a future hardware revision. The upgrade announcement also describes multiple Bluetooth 5.0 dongles for multi-device connections and synchronized acquisition. Applicable hardware, dongle configuration and synchronization conditions must be confirmed for the supplied version.
Upgrade descriptions follow the supplied manufacturer announcement. The amplifier description does not establish medical-device certification.
